Sampling & Layer Development
With a wide range of equipment

At our Technology & Application Center (TAC), we work together with you on the next generation of your coating applications.

We simulate layer stacks and their functionality, produce samples on laboratory and pilot scales, and measure and evaluate coating and substrate properties to meet diverse requirements.

As a result, you can test the coating performance of your product on relevant sample sizes in advance.

The TAC also offers you the chance to develop the product further while your equipment is being delivered. The results from the laboratory can be easily transferred to the equipment due to similar processes.

Several coating systems are available for substrates such as glass, polymer film, metal strip and silicon wafers. For basic testing, we use very flexible laboratory systems with smaller substrate formats. Thus, we are able to quickly define the appropriate parameter windows.

As a next step, we offer pilot runs on our in-house inline systems with larger substrates. This enables us to determine the fit with your process sequences through to the product. During this process, it is also possible to carry out further investigations of the samples.

All testing follows customer specifications or DIN standards for stability, corrosion resistance, adhesive strength, and chemical resistance.

Would you like to learn more? Then please feel free to contact us.

Servcices

Sampling & qualification of properties from a single source

Developing coating solutions
customized to customer requirements

Sampling customer-specific
layer systems

Qualifying & industrializing layer systems
together with customers

Measuring & testing according to
industry-specific requirements

Coating services
for pilot production

Applications
Equipment
CS200
  • Ideal for applications in the semiconductor and optics industries
  • High throughput
  • Compact dimensions
DREVA600
  • Very high surface hardness up to 80 GPa due to excellent sp3/sp2 ratio of the carbon layer
  • High throughput
  • High layer thickness of up to 30µm thick ta-C layers due to unique laser arc technology
Benefits

Gaining knowledge through simulation

 of layer composition & properties

Risk reduction & quicker market maturity

through industrial trials

Individual access to a variety

of coating materials & services

Optimal equipment configuration

through testing in a scalable process

CLEANROOM
  • Manufacturing of vacuum coating systems
  • Sampling & pilot deposition services
  • 600 m² semiconductor cleanroom including AMC capability
